Features & Benefits

  • Large, heavy duty, self-locking tow hitch handle
  • Fold up front support leg with spring loaded pin
  • Spring tension hose clamps for suction hose
  • Mistake free, easy to assemble hydraulic hoses
  • Top mounted hydraulic fluid port/filter for easy maintenance
  • 8-inch tapered spitting wedge for efficient splitting
  • Spring loaded auto lock horizontal beam lock
  • Spring loaded quick lock vertical beam lock
  • Heavy duty steel log catchers
  • Towable up to 45 mph
  • Operation: horizontal & vertical
  • Engine brand: recoil
  • Engine size: 196cc - Honda GX200
  • Beam style - full
  • Cycle time: 11 sec.
  • Max log length: 24 in.
  • Log catchers: yes - 2
  • Wedge type: 8 in. tapered
  • Pump stage/GPM: 2 stage / 13 gpm
  • Wheel size: 16 in. DOT 45 mph

Specifications

Color

Black

Country of Origin

China

Dimensions

26.8 x 70.1 x 19.3 in.
